T1 MINI RK3518 Android TV Box – Rockchip RK3518, Android 14, 4K, WiFi 6, 2GB and 16GB

The T1 MINI is a compact 4K Smart TV Box powered by the Rockchip RK3518 quad-core processor and Android 14. It delivers 4K Ultra HD with HDR10+, dual-band WiFi 6 and Bluetooth 5.2 for smooth streaming, and runs Netflix, YouTube, Hulu, Prime Video and TikTok on its 2GB of RAM and 16GB of storage.

📋 T1 MINI Smart TV Box Specifications

Category
Technical Details
Product Model
T1 MINI
Operating System
Android 14.0 (Optimized TV Interface)
Processor (CPU)
RK3518 Quad-core Cortex-A53 (1.3GHz)
Graphics (GPU)
Mali-G31 MP2 (Hardware 3D graphics acceleration)
System Memory
2GB DDR3
Storage (ROM)
16GB eMMC Flash
Wireless (Wi-Fi)
Built-in Dual-Band WiFi 6 (2.4G / 5.8GHz)
Bluetooth (BT)
Bluetooth 5.2

HDD File System
FAT16 / FAT32 / NTFS

🎬 Video, Audio & Display Capabilities

Feature
Supported Standards
Video Output
4K Ultra HD max resolution
Color Technology
HDR10+ / HDR Technology
Hardware Decoding
• H.265 HEVC MP-10@L5.1 up to 4K@30fps


• VP9-10 Profile-2 up to 4K@30fps


• H.264 AVC HP@L5.1 up to 4Kx2K@30fps


• MPEG-4/2/1, VC-1, RealVideo (up to 1080P@60fps)
Media Formats
Avi, Rm, Rmvb, Ts, Vob, Mkv, Mov, ISO, Wmv, Asf, Flv, Dat, Mpg, Mpeg
Audio Formats
MP3, WMA, AAC, WAV, OGG, AC3, DDP, TrueHD, DTS, DTS/HD, FLAC, APE
Photo Formats
HD JPEG, BMP, GIF, PNG, TIFF
Subtitle Support
SRT, SMI, SUB, SSA, IDX+USB

🔌 Hardware Interfaces & Physical Specs

  • HD Interface: HD 2.0 output up to 4K@30fps with HDR, CEC, and HDCP 2.2
  • USB Ports: 1 x USB 2.0 host
  • LAN Port: Not Supported (No LAN)
  • OSD Languages: English, French, German, Spanish, Italian, and other multilateral languages
  • Power Supply: DC 5V/2A
  • Product Size: 60 x 60 x 12 mm
  • Package Size: 210 x 140 x 40 mm
  • Packaged Weight: 0.5 KG
  • Color / Case: White / Plastic Material (Private Model)

Overview

The T1 MINI is a compact 4K Smart TV Box built around the Rockchip RK3518 quad-core Cortex-A53 processor with Mali-G31 graphics, running Android 14. It comes with 2GB of DDR3 memory and 16GB of eMMC storage, and plays 4K Ultra HD video with HDR10+. Dual-band WiFi 6 and Bluetooth 5.2 cover streaming and wireless accessories in a 60 x 60 x 12 mm body.

Key Features

  • 4K Ultra HD with HDR10+ (H.265 HEVC hardware decoding up to 4K at 30fps, VP9-10 and H.264 up to 4K at 30fps)
  • Android 14 with an optimized TV interface, plus WiFi 6 and Bluetooth 5.2
  • 2GB of DDR3 memory and 16GB of eMMC storage, with FAT16, FAT32 and NTFS file system support
  • HD 2.0 output up to 4K at 30fps with HDR, CEC and HDCP 2.2, plus a USB 2.0 host port
  • Compact 60 x 60 x 12 mm white plastic body, with OSD languages including English, French, German, Spanish and Italian

Target Applications

The T1 MINI is made for streaming on the TV: Netflix, YouTube, Hulu, Prime Video and TikTok in 4K Ultra HD with HDR10+. Its compact 60 x 60 x 12 mm body and dual-band WiFi 6 suit everyday viewing.
